| Type | Item | Parameter |
|---|---|---|
| Product Model | - | ST-600W |
| Input | AC Input | 8-bit Input Port 180-250V Rated Power 200W |
| DC Input | DC 5521: Photovoltaic Solar 15V-24V 5A / 120W Max | |
| AC Output 220V | AC Output Voltage | AC Plug AC 220V±5% |
| AC Output Watt | 600W | |
| Over-load Protection | 610W-800W | |
| AC Output Wave | Pure Sine Wave | |
| AC Output Peak | 1200w Peak Hold Time <50ms | |
| Frequency | 50Hz | |
| USB Output Ports | USB1 Output | QC 3.0 Max 12V/1.5A (18W) |
| USB2, USB3 Output | Total Output Max 5V/3A (15W) | |
| TC Output Ports | Type-C1 Output | PD 18W |
| DC Output Ports | DC1/DC2 Output | 12V/10Max |
| Wireless Output | - | 15W |
| Charging Time | 4-5H | From 10% to 100% (Auto Cut-off) |
| Charging Voltage | 14.6V±0.1V | The Voltage Until Full-charged |
| Protect Function | - | Short-circuit, Over-load, Over-heat, Over-voltage, Over-current, Short-voltage |
| LED Screen | Show Battery Charging Status | Battery Column Jumping |
| DC/AC/PD Working Condition | Showing Wattage | |
| Battery Pack | Type | Lithium Iron Phosphate |
| Pack Capacity | 12.8V-30AH / 384WH | |
| Cycle | >2000 | |
| Over-heat Protection | AC Over-heat Protection | ≥85ºC |
| Pack Over-heat Protection | ≥65ºC | |
| Boot Static | - | <1W |
| Scope of Application | - | Household Appliances, Mobile Phones, Tungsten Filament bulbs, Household Fans, Laptops, Rice Cooker, etc. Below 600W |
